Flexible LED Strip Light | COB | 5W/m 480 LED/m 24V Blue IP20 5mm 20m

COB flexible strip light offers a seamless visual linear light, eliminating any visual dots often found with traditional strip light.  Ideal for installations where the LED strip will not be mounted within profile but seen. The dotless design also allows the use of a less opaque (diffused) profile cover. This allows more light to transmitted without having to minimise dots.
The very narrow 5mm width makes this LED strip ideally suited to our micro series of profiles.



This LED strip light is rated at 5W/m, producing low levels of light.



COB is an acronym for: Chip on Board



The thermal efficiency of this LED strip means it does not require a heatsink allowing it to be mounted to almost any smooth hard surface.



This LED strip carries an IP rating of 20, this is an indoor / dry environment LED strip only. Please contact us if you require either IP54 or IP67.

Specifications

Electrical Data
Voltage 24 VDC
Wattage 1m 5.0 W
Current 1m 0.208 A
LED Data
Package Type COB (Chip on Board)
Chips LED 1
LEDs 1m 480
Photometric Data
Colour Temperature Blue
Colour Rendering Index Ra N/A
Luminous Flux 1m
Luminous Efficacy
Beam Angle 120°
Dimmable 1 ∼ 100% (refer data sheet)
Construction / Protection Data
Substrate Double layer FPCB
2oz
Mounting Double sided tape 3M 9080
IP Rating IP20
Operating Temperature -20 ∼ +70 C°
Storage Temperature -20 ∼ +50 C°
Dimensions
Cutting increments 50.0mm
Length 20m
Width 5.0mm
Height 4.0mm
Lifetime
Working Life 70,0000 hrs
